Lenovo Storage S3200 SFF with Dual SAS Controller (Part# : 64113B4)
ราคาปกติ
246,100.00
รวมภาษี
222,560.00
(Including VAT)
ก่อนภาษี
208,000.00
(Excluding VAT)
ลดไป
9.57%
ผ่อนชำระ(x6)
40,432.00 บ./เดือน
Lenovo Storage S3200 SFF with Dual SAS Controller Standard SET Host Interface : Eight 6/12Gb SAS Host ports (Four host ports per controller) (Mini-SAS HD, SFF-8644) Support RAID levels :RAID 0, 1, 5, 6, and 10 Drive bays : 24 SFF drive bays in the S2200 controller enclosure RAID controller cache :6 GB per controller. Battery-free cache protection with flash memory and supercapacitors. Host operating systems : Microsoft Windows Server 2012 and 2012 R2; Red Hat Enterprise Linux (RHEL) 6 and 7; SUSE Linux Enterprise Server (SLES) 10, 11, and 12; VMware vSphere 5.5 and 6.0. Standard software features : Intelligent Real-time Tiering for HDDs, Virtualized Storage Pools, Thin Provisioning, SSD Read Cache, Rapid RAID Rebuild, Snapshots - up to 128 targets. Cooling : Redundant cooling with two fans that are built into power supplies Power supply : Two redundant hot-swap 595 W AC power supplies. Hot-swap parts : RAID controllers, expansion modules, SFP/SFP+ transceivers, drives, power supplies/fans. Warranty : 3-year On-site warranty, parts-only limited warranty with 9x5 next business day by Lenovo (Thailand). Form factor : S3200 controller enclosure: 2U rack mount
Promotion Set 1 ราคาพิเศษเพียง 322,500 บาทเท่านั้น!!* + 5 x [00MM705] Lenovo Storage 2.5in 1TB 7.2k NL- SAS HDD + 4 x [00WE748] External MiniSAS HD 8644/MiniSAS HD 8644 1m cable + 4 x [00AE912] N2225 SAS/SATA HBA (Two external x4 mini-SAS HD connectors (SFF-8644)) + Free!! Lenovo Storage S2200 Basic Hardware Installation *Configuration ใน set 1 รองรับการเชื่อมต่อแบบ SAS กับ Server ได้ประมาณ 4 Servers โดยเชื่อมต่อผ่าน SAS Controller*
Warranty
:
3-year On-site warranty, parts-only limited warranty with 9x5 next business day by Lenovo (Thailand)
วิธีการจัดส่ง
:
ตรวจสอบ Stock สินค้า http://schema.org/OutOfStock
อัพเดทล่าสุด
:
31 พ.ค 16
ITEM DESCRIPTION Host Interface : Four 6/12Gb SAS Host ports (Two host ports per controller) (Mini-SAS HD, SFF-8644) Support RAID levels :RAID 0, 1, 5, 6, and 10
Drive bays : 24 SFF drive bays in the S2200 controller enclosure : Up to 192 SFF drive bays per system: (24 SFF drive bays in the E1024 drive expansion enclosure; up to 7x E1024 enclosures) RAID controller cache :6 GB per controller. Battery-free cache protection with flash memory and supercapacitors. Host operating systems : Microsoft Windows Server 2012 and 2012 R2; Red Hat Enterprise Linux (RHEL) 6 and 7; SUSE Linux Enterprise Server (SLES) 10, 11, and 12; VMware vSphere 5.5 and 6.0. Standard software features : Intelligent Real-time Tiering for HDDs, Virtualized Storage Pools, Thin Provisioning, SSD Read Cache, Rapid RAID Rebuild, Snapshots - up to 128 targets. Optional software features : Intelligent Real-time Tiering for SSDs, Snapshots - up to 1,024 targets, Asynchronous Replication. Performance : Dual controller configuration: Up to 120,000 random read IOPS (4 KB blocks) Up to 6.4 GBps sequential read throughput (512 KB blocks) Up to 5.3 GBps sequential write throughput (512 KB blocks) Cooling : Redundant cooling with two fans that are built into power supplies Power supply : Two redundant hot-swap 595 W AC power supplies. Hot-swap parts : RAID controllers, expansion modules, SFP/SFP+ transceivers, drives, power supplies/fans. Management interfaces : Web-based graphical user interface (GUI); Telnet, SSH, or Direct Connect USB command-line interface (CLI); HTTP scripting with XML encoding; SNMP and e-mail notifications Security features : Secure Socket Layer (SSL), Secure Shell (SSH), and SEDs Dimensions : SFF chassis: Height: 89 mm (3.5 in), width: 447 mm (17.6 in), depth: 519 mm (20.5 in) Weight : S3200 SFF: Minimum: 18.5 kg (40.8 lb); Maximum: 25.0 kg (55.2 lb) Warranty : 3-year On-site warranty, parts-only limited warranty with 9x5 next business day by Lenovo (Thailand). Form factor : S3200 controller enclosure: 2U rack mount
