ITEM DESCRIPTION
I/O ports and slots
- 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE- TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
- 4 SFP+ 1/10GbE ports
Dimensions
17.42(w) x 11.12(d) x 1.73(h) in (44.25 x 28.24 x 4.39 cm) (1U height)
Processor and memory
- ARM Cortex-A9 @ 800 MHz, 512 MB SDRAM 256 MB flash
Performance
100 Mb latency < 4.5 uSec : Packet size 64B
1000 Mb latency <2.2 uSec : Packet size 64B
10000 Mb latency <1.2 uSec : Packet size 64B
Throughput (Mpps) 130.95 Mpps : Packet size 64B
Switching capacity : 176 Gbps
Routing table size (# of static entries) : 32
MAC address table size (# of entries) : 16,000
Reliability MTBF (years) : 114
Environment
Operating temperature : 32°F to 104°F (0°C to 40°C)
Operating relative humidity : 15% to 95% @ 104°F (40°C)
Non-operating temperature : ‑40°F to 158°F (‑40°C to 70°C)
Non-operating relative humidity : 15% to 95% @ 140°F (60°C)
Altitude : Up to 10,000ft (3.048 Km)
Acoustic : Power: 0 dB (no fan)
Electrical Characteristics
Warrant
Frequency : 50-60 Hz
AC voltage : 100 - 127 / 200 - 240 VAC
Current : .8/.5 A
Maximum power rating : 36.9 W
Idle power : 16.8 W
PoE power : n/a
Power supply : Internal power supply
Safety
UL 60950-1; IEC 60950-1;EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1 UL 62368-1 Ed. 2; IEC 62368-1 Ed. 2; EN 62368-1:2014
Emissions
VCCI-CISPR 32, Class A; CNS 13438; ICES-003 Issue 6 Class A; FCC CFR 47 Part 15, Class A; EN 55032: 2015 +AC:2016 / CISPR-32, Class A
Warranty
- HPE Limited Lifetime warranty
|
 |
|
 |
|
